Three Wheel "Slack Action" Versatility Grinder | Dynabrade 64861

Dynabrade 64861 Three Wheel Variable Speed Versatility Grinder, Slack-Action.

Variable Speed Versatility Grinder, Slack-Action, 240 V, 1HP

• Machine offers simplified design that eliminates belt tension rollers to reduce maintenance costs.Design also allows greater use of abrasive belt slack areas. Operator has flexibility to finish workpiece on belt slack in a variety of positions, for optimum efficiency.
• Versatility Grinder powers 72" abrasive belts in widths from 1/4" to 2", to provide a wide variety of finishing solutions.Ideal for use on castings and forgings, turbine blades, medical implants, investment castings and more.
• Ideal for use on castings and forgings, turbine blades, medical implants, investment castings and more. Adjustable air belt tensioning provides constant control. Pivoting arm assembly for operator comfort.
• Unit has includes efficient through-housing 4" vacuum port for dust control with optional vacuum scoop (64932).

Specifications:

• Abrasive Belt Size Inch (mm) - 1/4"(6,35) - 2" (50,8) x 72" (1828,8)
• Frequency - 50/60 Hz
• Height Inch (mm) - 22" (559)
• Max. SFPM (SMPM) - 600-4,000 (183-1,219)
• Phase - 1
• Sound Level dB(A) - 82
• Voltage - 240V (AC)
• hp (W) - 1 (746)
• Length - 33" (838)
